6ES7154-4AB10-0AB0 SIEMENS SIMATIC DP PROFINET Interface Module IM 154-4 PN

Ask Lasest Price
Brand Name :	SIEMENS
Model Number :	6ES7154-4AB10-0AB0
Certification :	CE
Payment Terms :	L/C, T/T
Supply Ability :	10PC
Delivery Time :	5-10days

Add to Cart

Product Details
Company Profile

6ES7154-4AB10-0AB0 SIEMENS SIMATIC DP PROFINET Interface Module IM 154-4 PN

Technical data

		SIMATIC DP, PROFINET Interface module IM 154-4 PN, High Feature for ET 200 PRO, Integrated switch, incl. termination module, connection module in PN 6ES7194-4A.00-0AA0 order separately
General information
Product type designation		IM 154-4 PN HF
Vendor identification (VendorID)		0x002A
Device identifier (DeviceID)		0x0305
Supply voltage
Rated value (DC)		24 V
Reverse polarity protection		Yes; against destruction
Short-circuit protection		Yes; Fuse in lower part is exchangeable, the fuse on the IM-LP is not
power supply according to NEC Class 2 required		No
Load voltage 2L+
● Rated value (DC)		24 V
● Reverse polarity protection		Yes; against destruction
Input current
from supply voltage 1L+, max.		400 mA; Dependent on terminal module, typ. maximum value for FO connection method, full load on RWB and 20.4 V input voltage
Power loss
Power loss, typ.		6 W; dependent on terminal module, typ. maximum value for CU connection method, full load on RWB, for FO the value is approx. 0.7 W higher
Address area
Addressing volume
● Inputs		256 byte
● Outputs		256 byte
Interfaces
Interfaces/bus type		PROFINET IO
Interface types
M12 port
● Autonegotiation		Yes
● Transmission rate, max.		100 Mbit/s
Protocols
Protocols (Ethernet)
● SNMP		Yes
● ping		Yes
● ARP		Yes
Redundancy mode
Media redundancy
— MRP		Yes
Interrupts/diagnostics/status information
Alarms
● Diagnostic alarm		Yes; Parameterizable
● Hardware interrupt		Yes; Parameterizable
Diagnostics indication LED
● MAINT LED		Yes
● LINK LED		Yes
● RX/TX LED		Yes
● For load voltage monitoring		Yes
● Bus fault BF (red)		Yes
● Group error SF (red)		Yes
● Monitoring 24 V voltage supply ON (green)		Yes
Parameter
Swapping interrupt		Parameterizable
Startup if setpoint not equal to actual configuration		Parameterizable
Hot swapping of modules		possible
Potential separation
between backplane bus and electronics		No
between supply voltage and electronics		Yes
Isolation
Isolation tested with		707 V DC (type test)
Degree and class of protection
IP degree of protection		IP65/67
Ambient conditions
Ambient temperature during operation
● min.		-25 °C
● max.		55 °C
Ambient temperature during storage/transportation
● min.		-40 °C
● max.		70 °C
Dimensions
Width		135 mm
Height		130 mm
Depth		60 mm
Weights
Weight, approx.		490 g
