IFM Capacitive sensor KF5001 KFA3040BBPKG/NI/US

Ask Lasest Price
Brand Name :	IFM
Model Number :	KF5001
Certification :	CE
Price :	USD
Payment Terms :	L/C, T/T
Supply Ability :	100
Delivery Time :	10-12Days

Add to Cart

Product Details
Company Profile

IFM Capacitive sensor KF5001 KFA3040BBPKG/NI/US

The IFM KF5001 KFA3040BBPKG/NI/US is a capacitive sensor manufactured by IFM Electronic GmbH. Here's some information about the capacitive sensor:

1. Model: KF5001 KFA3040BBPKG/NI/US
2. Manufacturer: IFM Electronic GmbH
3. Function: The capacitive sensor is designed to detect the presence or absence of various materials or objects based on changes in capacitance.
4. Sensing Principle: Capacitive sensors work by measuring changes in the electrical capacitance between the sensor and the target object. When an object enters the sensing range, it causes a change in capacitance, triggering the sensor's output.
5. Housing Type: The sensor is likely housed in a specific enclosure or housing design. Unfortunately, I do not have specific information about the housing type for this particular model.
6. Electrical Connection: The sensor supports a specific electrical connection type, indicated by the "/US" in the model name. The exact type of electrical connection may vary, and you should consult the product documentation or datasheet for more details.
7. Output Type: The sensor provides an output signal that indicates the presence or absence of the detected object. The specific output type for this model, such as NPN (sourcing) or PNP (sinking), can be identified by the "BB" or "NB" in the model name. Unfortunately, I do not have specific information about the output type for this particular model.
8. Application: Capacitive sensors like the KF5001 KFA3040BBPKG/NI/US are commonly used in industrial automation, robotics, packaging, and material handling applications for detecting solid or liquid objects, level sensing, and proximity detection.

For detailed specifications, installation guidelines, and compatibility information for the IFM KF5001 KFA3040BBPKG/NI/US capacitive sensor, it is recommended to consult the official documentation provided by IFM Electronic GmbH or contact their technical support. They will be able to provide you with accurate and up-to-date information based on your specific requirements and the latest product information available.

Product characteristics

Electrical design	PNP
Output function	normally open
Sensing range [mm]	1...6
Housing	threaded type
Dimensions [mm]	M12 x 1 / L = 60

Application

Media

dry bulk material; liquids

Electrical data

Operating voltage [V]	10...36 DC; ("supply class 2" to cULus)
Current consumption [mA]	< 12
Protection class	III
Reverse polarity protection	yes

Outputs

Electrical design	PNP
Output function	normally open
Max. voltage drop switching output DC [V]	2.5
Permanent current rating of switching output DC [mA]	100
Switching frequency DC [Hz]	50
Short-circuit proof	yes
Overload protection	yes

Detection zone

Sensing range [mm]	1...6
Sensing range adjustable	yes
Factory setting sensing range [mm]	4
Real sensing range Sr [mm]	4 ± 10 %

Accuracy / deviations

Correction factor	glass: 0.6 / water: 1 / ceramics: 0.5 / PVC: 0.4
Hysteresis [% of Sr]	1...15
Switch point drift [% of Sr]	-20...20

Operating conditions

Ambient temperature [°C]	-25...70
Protection	IP 65
Increased immunity	yes

Tests / approvals

EMC

EN 60947-5-2

MTTF [years]

636

Mechanical data

Weight [g]	39.3
Housing	threaded type
Mounting	flush mountable
Dimensions [mm]	M12 x 1 / L = 60
Thread designation	M12 x 1
Materials	stainless steel (316L/1.4404); PEEK
