SIEMENS PLC SIMATIC S7-1500 CPU 1514SP-2 PN 6ES7514-2DN03-0AB0
CENTRAL PROCESSING UNIT WITH WORK
Product Introduction:
The SIEMENS PLC SIMATIC S7-1500 CPU 1514-2 PN 6ES7514-2DN03-0AB0 is
a central processing unit (CPU) specifically designed for
industrial automation applications. It is part of the Siemens
SIMATIC S7-1500 series, known for its advanced functionality, high
performance, and reliability.
Product Information and Specifications:
- Model: CPU 1514-2 PN 6ES7514-2DN03-0AB0
The CPU 1514-2 PN is equipped with a powerful processor that
ensures rapid and efficient execution of control programs. It
supports multiple programming languages, including ladder logic,
function blocks, and structured text, providing flexibility and
ease of use for complex control tasks.
Regarding memory capacity, the CPU 1514-2 PN offers ample storage
space for both program and data. While specific details were not
provided in the query, typical configurations of the CPU include
program memory ranging from 500 KB to 1.5 MB and data memory
ranging from 500 KB to 1 MB. This memory capacity allows users to
store their control programs and necessary data structures for the
PLC's operation.
Designed to operate in demanding industrial environments, the CPU
1514-2 PN delivers reliable and precise control for applications
such as manufacturing, process control, and machine automation. It
supports a wide range of communication interfaces, including
PROFINET, enabling seamless integration with other devices and
systems within the automation network.
The CPU 1514-2 PN includes an onboard PROFINET interface,
simplifying network connections and facilitating communication with
other devices in the automation system. Additionally, it supports
distributed I/O, allowing for flexible and scalable system
architectures.
Programming and configuration of the CPU 1514-2 PN is typically
done using Siemens' TIA Portal (Totally Integrated Automation
Portal) software. The TIA Portal provides a comprehensive
engineering environment for efficient programming, simulation, and
diagnostics, ensuring easy development and maintenance of
automation projects.
Product Attributes:
- Model: CPU 1514-2 PN 6ES7514-2DN03-0AB0
- Processor: Powerful processor for rapid and efficient control
program execution
- Programming Languages: Supports ladder logic, function blocks,
and structured text
- Memory Capacity: Ample storage space for program and data
- Communication Interfaces: Supports PROFINET
- Onboard PROFINET Interface: Simplifies network connections and
device communication
- Distributed I/O Support: Enables flexible and scalable system
architectures
- Engineering Software: Programmed and configured using Siemens'
TIA Portal
- Suitable for: Manufacturing, process control, and machine
automation applications
In summary, the SIEMENS PLC SIMATIC S7-1500 CPU 1514-2 PN
6ES7514-2DN03-0AB0 is a reliable CPU with advanced features,
sufficient memory capacity, and seamless communication
capabilities. It provides efficient and precise control for various
industrial processes, making it well-suited for a wide range of
industrial automation applications.
| General information |
| Product type designation | CPU 1514SP-2 PN |
| HW functional status | FS01 |
| Firmware version | V3.0 |
| Product function |
| ● I&M data | Yes; I&M0 to I&M3 |
| ● Module swapping during operation (hot swapping) | Yes; Multi-hot swapping |
| ● Isochronous mode | Yes; only with PROFINET; with minimum OB 6x cycle of 375 µs |
| Engineering with |
| ● STEP 7 TIA Portal configurable/integrated from version | V18 (FW V3.0) |
| Configuration control |
| via dataset | Yes |
| Control elements |
| Mode selector switch | 1 |
| Supply voltage |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| Reverse polarity protection | Yes |
| Mains buffering |
| ● Mains/voltage failure stored energy time | 10 ms |
| Input current |
| Current consumption (rated value) | 0.51 A |
| Current consumption, max. | 0.7 A |
| Inrush current, max. | 1.34 A; Rated value |
| I²t | 0.3 A²·s |
| Power |
| Infeed power to the backplane bus | 8.05 W |
| Power loss |
| Power loss, typ. | 3.5 W |
| Memory |
| Number of slots for SIMATIC memory card | 1 |
| SIMATIC memory card required | Yes |
| Work memory |
| ● integrated (for program) | 600 kbyte |
| ● integrated (for data) | 3.5 Mbyte |
| Load memory |
| ● Plug-in (SIMATIC Memory Card), max. | 32 Gbyte |
| Backup |
| ● maintenance-free | Yes |
| CPU processing times |
| for bit operations, typ. | 6 ns |
| for word operations, typ. | 7 ns |
| for fixed point arithmetic, typ. | 9 ns |
| for floating point arithmetic, typ. | 37 ns |
| CPU-blocks |
| Number of elements (total) | 8 000; Blocks (OB, FB, FC, DB) and UDTs |
| DB |
| ● Number range | 1 ... 60 999; subdivided into: number range that can be used by the
user: 1 ... 59 999, and number range of DBs created via SFC 86: 60
000 ... 60 999 |
| ● Size, max. | 3.5 Mbyte; For DBs with absolute addressing, the max. size is 64 KB |
| FB |
| ● Number range | 0 ... 65 535 |
| ● Size, max. | 600 kbyte |
| FC |
| ● Number range | 0 ... 65 535 |
| ● Size, max. | 600 kbyte |
| OB |
| ● Size, max. | 600 kbyte |
| ● Number of free cycle OBs | 100 |
| ● Number of time alarm OBs | 20 |
| ● Number of delay alarm OBs | 20 |
| ● Number of cyclic interrupt OBs | 20; With minimum OB 3x cycle of 250 µs |
| ● Number of process alarm OBs | 50 |
| ● Number of DPV1 alarm OBs | 3 |
| ● Number of isochronous mode OBs | 1 |
| ● Number of technology synchronous alarm OBs | 2 |
| ● Number of startup OBs | 100 |
| ● Number of asynchronous error OBs | 4 |
| ● Number of synchronous error OBs | 2 |
| ● Number of diagnostic alarm OBs | 1 |
| Nesting depth |
| ● per priority class | 24 |
| Counters, timers and their retentivity |
| S7 counter |
| ● Number | 2 048 |
| Retentivity |
| — adjustable | Yes |
| IEC counter |
| ● Number | Any (only limited by the main memory) |
| Retentivity |
| — adjustable | Yes |
| S7 times |
| ● Number | 2 048 |
| Retentivity |
| — adjustable | Yes |
| IEC timer |
| ● Number | Any (only limited by the main memory) |
| Retentivity |
| — adjustable | Yes |
| Data areas and their retentivity |
| Retentive data area (incl. timers, counters, flags), max. | 512 kbyte; In total; available retentive memory for bit memories,
timers, counters, DBs, and technology data (axes): 472 KB |
| Flag |
| ● Size, max. | 16 kbyte |
| ● Number of clock memories | 8; 8 clock memory bit, grouped into one clock memory byte |
| Data blocks |
| ● Retentivity adjustable | Yes |
| ● Retentivity preset | No |
| Local data |
| ● per priority class, max. | 64 kbyte; max. 16 KB per block |
| Dimensions |
| Width | 100 mm |
| Height | 117 mm |
| Depth | 75 mm |
| Weights |
| Weight, approx. | 265 g |
