SIEMENS SIMATIC HMI 6AV6647-0AG11-3AX0 TP1500 15 inch Basic Color PN

SIMATIC HMI TP1500 Basic Color PN, Basic Panel, Touch operation, 15" TFT display, 256 colors, PROFINET interface, configurable as of WinCC flexible 2008 SP2 Compact/ WinCC Basic V10.5/ STEP 7 Basic V10.5, contains open-source software, which is provided free of charge see enclosed CD

Product Name: SIEMENS SIMATIC HMI 6AV6647-0AG11-3AX0 TP1500 15 inch Basic Color PN

Introduction:
The SIEMENS SIMATIC HMI 6AV6647-0AG11-3AX0 TP1500 Basic Color PN is a 15-inch operator panel designed for Human Machine Interface (HMI) applications in industrial automation. It offers advanced features and functionality for controlling and monitoring processes in a user-friendly manner.

Origin: Germany

Product Specifications:
- Product Name: SIEMENS SIMATIC HMI 6AV6647-0AG11-3AX0 TP1500 Basic Color PN
- Operator Panel Type: TP1500 Basic Color PN
- Display: Color TFT LCD
- Display Size: 15 inches
- Resolution: 1024 x 768 pixels
- Communication Interface: PROFINET (PN)
- Number of Function Keys: 16
- Touchscreen: Resistive
- Memory: 10 MB
- IP Rating: IP65 (front panel)
- Operating Temperature: 0°C to 45°C
- Dimensions (W x H x D): 364 mm x 289 mm x 65 mm
- Weight: Approximately 4.8 kg

Product Features:
- 15-inch color TFT LCD display for clear and vibrant visualization of information.
- Resistive touchscreen for intuitive and precise operation.
- Supports PROFINET communication interface for seamless integration with industrial automation systems.
- 10 MB memory capacity for storing projects and data.
- Features 16 function keys for quick access to frequently used functions.
- Compact and rugged design with an IP65-rated front panel for protection against dust and water.
- Designed for easy installation and integration with the control system.
- Compatible with SIMATIC STEP 7 engineering software for efficient project development.

Functionality:
- The TP1500 Basic Color PN operator panel allows operators to control and monitor industrial processes.
- The 15-inch color TFT LCD display provides clear and vibrant visualization of information, enhancing operator understanding.
- The resistive touchscreen enables intuitive and precise operation, allowing for easy interaction with the HMI.
- The PROFINET communication interface allows for seamless integration with the industrial control system, enabling real-time data exchange.
- The panel's 10 MB memory capacity provides ample storage for projects and data.
- The 16 function keys provide quick access to frequently used functions, enhancing operational efficiency.
- The compact and rugged design, along with the IP65-rated front panel, ensures durability and protection in harsh industrial environments.
- The panel is designed for easy installation and integration with the control system, reducing setup time.
- It is compatible with SIMATIC STEP 7 engineering software, enabling efficient project development and configuration.

Please note that for detailed technical specifications and a comprehensive list of features, it is recommended to refer to the official documentation or product datasheet provided by SIEMENS.
